        Integra Multigas® NIOSH Respirator

        with replacement filters

        Compact, lightweight and flexible design which adapts and fits perfectly to the face and offers a unique and innovative combined protection, reducing risks of non-compatibility, non-conformity and mist build-up. Large central non-return exhalation valve which reduces the breathing resistance for the user and keeps moisture build-up inside the mask to a minimum.

        Lightweight, non-slip strap that is easily adjusted in 4 positions for improved comfort and to allow safe use even in high humidity or wet conditions.

        Elipse Integra come in 2 sizes.

        Items code (click to buy on Amazon):
        SPR630 S/M
        SPR631 M/L

        TDS

        Ask for information

        Properties

        This mask is recommended for organic, inorganic, chemical and ammonia based gases into industrial applications.

        The gas cartridges contain specific activated carbon granules with optimised characteristics such as pore size, grain size, activity level, density etc, which provide a maximum adsorption performance and a really low breathing resistance.

        Each respirator is supplied pre-fitted with two gas filters that can be replaced.

        The lens is designed in Polycarbonate and can withstand 120 m per second impacts. The coating applied meets (N) Anti Fog and exceeds the standard (K) anti-scratch coating seen on the market for a longer durability.

        Elipse Integra is compatible with the current Elipse filter range.

        Characteristics

        Certifications
        NIOSH Approval number: Multigas TC-23C-3539. ANSI Z87+ Approved.
        Efficiency
        At 1000 ppm: Cyclohexane >70 min. Chlorine >20 min. Hydrogen sulphide > 40 min. Hydrogen cyanide > 25 min. Sulphur dioxide > 20 min. Ammonia > 50 min.
        Materials
        Medical grade TPE conforms to ISO 10993-10: 2010 for irritations. Mask body latex and silicone free, odour free. Valve Body in Nylon, Inhalation/Exhalation diaphragm in Silicone. 4 point adjustable elastic head and neck strap with comfort pad in TPE.
        Filters
        Mechanical type multi-layer HESPA Synthetic media with TPE flexible overmolded / encapsulated.
        Storage Life
        3 years for masks and filters.

        Applications

        • For multiple gases and vapours
        • Ammonia gases

        Product Variants

        Multiple versions of Integra Multigas® NIOSH Respirator are available.

        Product Variants

        3 available results

        1. Elipse Multigas Filter Kit
          SPR483
          Elipse Multigas Filter Kit
          Elipse Multigas Filter Kit
          Dimension
          11 x 97 x 53 mm
          Filter media
          HESPA (High Efficiency Synthetic Particulate Air filter)
          Materials of construction
          Mask Body: TPE (Thermo Plastic Elastomer)
          Notes
          Filter Multigas - smaller, thinner, more flexible, innovative encapsulation design
          Pore size (µm)
          0.3
          Ref. standard
          CA 29.416, EN140, EN143
          Retention range
          99.95% (minimum efficiency)
          Temperature
          -5°C +55°C
          Weight (g)
          Mask + Filter: 132 g, Mask body: 97.6 g
        2. Elipse Integra S/M Multigas
          SPR630
          Elipse Integra S/M Multigas
          Elipse Integra S/M Multigas
          Dimension
          175 x 180 x 180 mm
          Filter media
          HESPA (High Efficiency Synthetic Particulate Air filter)
          Materials of construction
          Mask Body: TPE (Thermo Plastic Elastomer)
          Notes
          Combined safety goggle and half mask for protection from dust, metal fumes, oil and water mists and micro-organisms, i.e. bacteria and viruses
          Pore size (µm)
          0.3
          Ref. standard
          EN140, EN143
          Retention range
          99.95% (minimum efficiency)
          Temperature
          -5°C +55°C
        3. Elipse Integra M/L Multigas
          SPR631
          Elipse Integra M/L Multigas
          Elipse Integra M/L Multigas
          Dimension
          175 x 180 x 180 mm
          Filter media
          HESPA (High Efficiency Synthetic Particulate Air filter)
          Materials of construction
          Mask Body: TPE (Thermo Plastic Elastomer)
          Notes
          Combined safety goggle and half mask for protection from dust, metal fumes, oil and water mists and micro-organisms, i.e. bacteria and viruses
          Pore size (µm)
          0.3
          Ref. standard
          EN140, EN143
          Retention range
          99.95% (minimum efficiency)
          Temperature
          -5°C +55°C
